Product Description
The HBFS1 Jemm Suspended LED High Bay luminaire provides controlled illumination for general and task lighting designed for the harsh environments found in food processing and heavy manufacturing facilities. The luminaire utilizes high efficiency LEDs to reduce maintenance and lower energy costs. These high-quality durable fixtures are used in food and beverage processing, meat and poultry processing, livestock agricultural facilities, heavy industrial, and manufacturing facilities. Typical lighting applications include meat and poultry processing, food and beverage processing, cold storage, harsh environment industrial, vehicle wash facilities, pharmaceutical and scientific labs. Mounting heights of 16 to 20 feet can be used based on light level and uniformity requirements.
Housing: Die Casted Aluminum Alloy
16L = 100W and 24L = 150W
Listing & Ratings: ETL: Listed for Wet Locations, ANSI/UL 1598, 8750. ETL Sanitation certified to National Sanitation Foundation ANSI NSF2, Food Splash Zone. IP66 Sealed LED Compartment, Pressure wash rated to 1400 PSI.
Finish: Common Epoxy Resin Powder Coat White or Grey
Lens: Clear UV-Stabilized Polycarbonate or Optional DR Acrylic Lens. Medium Distribution (80˚ Beam).
Mounting Options: Suspended Using Die Cast Aluminum Captive Hook.
EasyLED LED: Aluminum Boards
Dimensions 5.4”H x 17.9”W
Lumen: 16,000 or 24,000 lumens
Power Input: Includes 6’ Yellow Cable (5-Conductor Wire to Pigtails) (Black, White, Green, Purple, Gray)
Driver: Electronic Driver, 120-277V, 50/60Hz or 347-480V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 4KV to 6kV depending on wattage.
0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
